Steel Props

Adjustable Steel Props 2.0-4.0m | Heavy Duty Scaffolding Shoring Jacks Q235

Heavy duty adjustable steel props: 2.0m-6.0m range, Q235 steel, 48mm/60mm tubes. For concrete formwork and slab support. Hot-dip galvanized or painted. ISO 9001 factory in Tianjin.

Adjustable Steel Props 2.0m–4.0m | Heavy Duty Scaffolding Shoring Jacks

Our adjustable steel props (also called acrow props, shoring jacks, or telescopic steel props) are the workhorse of concrete formwork support. Used to temporarily support slabs, beams, and walls during construction — they are infinitely reusable, require no tools for assembly, and have no loose parts to misplace.

Manufactured from Q235 structural steel with threaded collar adjustment. Available in both heavy duty (48mm/60mm tubes) and light duty (40mm/48mm tubes) configurations. Height range: 1.6m to 6.0m, customizable.

Heavy Duty Prop Specifications

Model	Min Height	Max Height	Inner Tube	Outer Tube
Sino-1033	2.0m	3.8m	48mm×2.0mm	60mm×2.0mm
Sino-1034	2.2m	3.9m	48mm×2.0mm	60mm×2.0mm
Sino-1035	2.4m	4.0m	48mm×2.5mm	60mm×2.0mm
Sino-1036	2.5m	4.5m	48mm×3.0mm	60mm×2.5mm
Sino-1037	3.6m	5.0m	48mm×3.0mm	60mm×2.5mm
Sino-1038	4.0m	6.0m	48mm×3.5mm	60mm×3.0mm

Light Duty Prop Specifications

Model	Min Height	Max Height	Cup Nut	Inner Tube	Outer Tube
Sino-1039	1.6m	3.0m	M60×4.0mm	40mm×2.0mm	48mm×2.0mm
Sino-1042	1.8m	3.5m	M60×4.0mm	40mm×2.0mm	48mm×2.0mm
Sino-1045	2.0m	3.5m	M60×4.0mm	40mm×2.0mm	48mm×2.0mm

Also available: M68 and M72 cup nut variants with 48mm/56mm and 48mm/60mm tube combinations.

What to Check Before Buying Adjustable Steel Props 2.0-4.0m | Heavy Duty Scaffolding Shoring Jacks Q235

Choose Adjustable Steel Props 2.0-4.0m | Heavy Duty Scaffolding Shoring Jacks Q235 working height in the middle 60% of its range — never at maximum extension.
For Adjustable Steel Props 2.0-4.0m | Heavy Duty Scaffolding Shoring Jacks Q235, verify inner/outer tube wall thickness: heavy duty uses 48/60mm tubes with 2.0-3.5mm walls.
Check surface treatment on Adjustable Steel Props 2.0-4.0m | Heavy Duty Scaffolding Shoring Jacks Q235: hot-dip galvanized for outdoor storage, painted for indoor use.
Confirm Adjustable Steel Props 2.0-4.0m | Heavy Duty Scaffolding Shoring Jacks Q235 steel grade: Q235 is standard, request Q345 for higher load applications.
Ensure Adjustable Steel Props 2.0-4.0m | Heavy Duty Scaffolding Shoring Jacks Q235 comes with compatible U-head forks and base plates for your formwork system.

Frequently Asked Questions About Adjustable Steel Props 2.0-4.0m | Heavy Duty Scaffolding Shoring Jacks Q235

Q: What is the minimum order quantity for Adjustable Steel Props 2.0-4.0m | Hea...?
A: Standard MOQ is one 20ft container (approximately 25-28 tons). For trial orders, we can arrange LCL shipments starting from 1 ton with a small logistics premium. Contact us with your required specifications for a precise quotation.

Q: How long does delivery take for Adjustable Steel Props 2.0-4.0m | Hea...?
A: Production lead time is 15-25 days after deposit confirmation for standard orders. Large quantity orders (10+ containers): 25-35 days. Sea freight transit time varies by destination port — typically 20-45 days. Contact us with your destination for an estimated delivery schedule.

Q: Can I get samples of Adjustable Steel Props 2.0-4.0m | Hea... before placing a bulk order?
A: Yes. We provide free samples for existing stock items (you cover freight cost). For custom specifications, a sample fee applies which is fully deducted from your bulk order. Typical sample delivery: 3-5 working days after confirmation.
